Displayport Connector vs Case Issue

While upgrading the KVM switch to Displayport, there were some problems with cables. After sending a cable back that didn’t work, the replacement finally arrived. The new cable didn’t seat properly into the GTX 1050 Card in the Cooler Master NS200 case either.

After looking at a cable that worked – 6 ft- and then at the cable needed – 10 ft – the issue was discovered. The case has a bump next to the card interface that interferes with one of the cables and not the other. The 6 ft cable is slightly flatter where the bump is and so clears it to seat properly into the graphics card.

The top left pictures shows the CM NS200 case detail next to the graphics card. The Mini-ITX card does not allow another position for the graphics card. The top left picture shows a Displayport connector that works. The bottom left shows the before and after – the two ends – of the cable that does not work. The right connector has been shaved with an Exacto knife to allow it to fit past the bump and seat properly. The bottom right picture shows a detail of the modification of the cable.

Looks like not every one agrees on the clearance required for displayport cables. So beware if you rig doesn’t work as expected.


Experiments in 4K

Ever the experimenter, I recently got a Samsung 40″ Class MU6300 4K UHD TV. As you can see from the price, I didn’t choose MSRP.  I was just checking what prices were doing on UHD TVs and came across a deal on a refurbished model at almost 50% off.

The first one arrived broken. But I didn’t despair . After calling Walmart customer service, they agreed to ship me another and emailed a return label for the broken one.

Apparently, the first one had been dropped before it was packed since it was in some serious bubble wrap and there was no mark on the box. Oh well. The pictures above were taken when it was plugged in and the damage was not evident when the TV was not plugged in.

Continue reading “Experiments in 4K”

Engadget – Advertising to the Max

Engadget with Ghostery

I use an Ad Blocker – Ghostery – in FireFox. There are several reasons for this:

  1. To keep down the tracking. I know that ad-blocking doesn’t really stop tracking. Of course I disable 3rd Party cookies and enable “Tracking Protection”. But I don’t expect that this really stops tracking since there are so many ways around Ad Blockers and Tracking Protection.
  2. To help prevent Malware infections. There have been many cases of malicious advertisers leaking their malware through ads into systems. Advertisers, including even Google, have been the source of malware attacks since they do not sufficiently vet their advertisers.
  3. To increase the performance of page loading, since all that Ad Ware and Tracking nonsense is often many times the size of the page itself.

Most of my web experience with Ghostery Enabled is just fine. I can purchase items online on Amazon, Newegg and many other sites. I can read most news sites just fine. Slashdot and many other sites show ads in a way that Ghostery does not block, but that is not intrusive or objectionable.

Continue reading “Engadget – Advertising to the Max”

Get Ready for 4K!

My main computer area has four computers, a KVM switch, and it has for a long time had a single 1080 monitor. Recently I was doing some video editing and moved the recently purchased 2K – 2560×1440 – monitor into that area and hooked it up with a separate cable.

There is the network backup machine – lower left – two Alienware cases – with modern Core i-7 upgrades, and a small Core i5 Linux Mint system. All the systems have SSD system drives of course with various large data / video HDs from Western Digital. And of course there is a 1 GBPS 8 port network hub.

The KVM switch is many years old and is DVI, not even HDMI. It has served well and faithfully, but it’s time for an upgrade.

Some research indicated that IOGear has recently come out with a 4K, Displayport, 2 Monitor KVM switch, so it’s time for an upgrade. This switch is $599 MSRP on the IOGear site, but it’s only $442 on Newegg. Hurray. Update: See below. It’s all working now.

Continue reading “Get Ready for 4K!”
